Commercial Overhead Garage Door Opener Repair Airdrie
Airdrie Mobile commercial garage door & overhead door opener repair & Commercial garage door & Overhead door opener replacements
Door Surgeon commercial overhead garage door opener repair service in Airdrie stocks commercial door openers that are made to last. Door Surgeon's commercial garage door opener serviceman will come to your broken commercial garage door operator and fix, repair, adjust your commercial garage door operator or install a new commercial garage door opener. Door Surgeon's overhead door motor repair and replacement servicemen have a variety of replacement parts available to once again get your overhead door operator working in Airdrie.
It's time to get Door Surgeon's overhead door opener servicemen working for you. Door Surgeon offers emergency overhead door opener repair, fix, adjustment or new overhead garage door opener installation service.
Door Surgeon Airdrie Commercial Overhead Garage Door Opener Repair Team is Here to Help
Commercial Overhead Garage Door Opener Repair Team Leaders & Mobile Professional Overhead Garage Door Opener Repair Technicians
Josh
Journeyman
Locksmith
Door & Hardware
Expert
Paul
Journeyman
Locksmith
Door & Hardware
Expert
JJ
Door Surgeon
Garage Door
Expert
Tyler
Locksmith
Inventory
Manager
Patrick L
Journeyman
Locksmith
Product Consultant
Matt
Journeyman
Locksmith
Nahum
Journeyman
Locksmith
Justin
Locksmith
Robbie
Locksmith
Lucas
Locksmith
Carlin
Journeyman
Locksmith
MacKenzie
Journeyman
Locksmith
Province-Wide Mobile Service
15 Mobile Service Trucks
• Door Surgeon™ overhead garage door opener repair service trucks are stocked with a variety of common repair and replacement parts.
• Service trucks carry a wide variety of tools to complete on-site installation and repairs.
• Door repair service trucks are stocked with a variety of common repair and replacement parts.
• Service trucks carry a wide variety of tools to complete on-site installation and repairs.
Serving: Airdrie and surrounding areas.
Manaras New Overhead Commercial Garage Door Openers supplied and installed in Airdrie:
The following commercial series overhead garage door opener brands can be replaced or repaired: Liftmaster commercial overhead garage door opener & Manaras commercial overhead garage door opener. Doorlec commercial overhead garage door opener, Genie commercial overhead garage door opener. Lynx commercial overhead garage door opener, Overhead Door Co. commercial overhead garage door opener. Wayne Dalton commercial overhead garage door opener, Rytec commercial overhead garage door opener. Raynor commercial overhead garage door opener, Mighty Mule commercial overhead garage door opener. Lawrence commercial overhead garage door opener, Micanan commercial overhead garage door opener & Grifco commercial overhead garage door opener.
As well as: Linear commercial overhead garage door opener, Guardian commercial overhead garage door opener. Zap Motors commercial overhead garage door opener Cookson commercial overhead garage door opener. Cornell commercial overhead garage door opener, Kinnear commercial overhead garage door opener. Miller Edge commercial overhead garage door opener, Besam Assa Abloy commercial overhead garage door opener. Entrematic commercial overhead garage door opener, Power Master commercial overhead garage door opener. Chain Hoist commercial overhead garage door opener, Garaga commercial overhead garage door opener. Zhejiang Xianfeng commercial overhead garage door opener, Link Controls commercial overhead garage door opener. Sommer commercial overhead garage door opener, Richard Wilcox commercial overhead garage door opener. Somfy commercial overhead garage door opener.
Whether you are looking for a repair or commercial-industrial overhead door opener replacement, Door Surgeon's sales and service parts counter has you covered with commercial overhead door openers that are explosion Proof, Water Proof, NEMA 4, NEMA 7/9 overhead garage door openers. If it's time to have repairs made on your commercial garage door or repairs made to your overhead door, it's time to get Door Surgeon's mobile commercial garage door servicemen working for you.
OPERA MH
New 1/2 HP Commercial / Industrial Medium Duty Jack Shaft Commercial Overhead Door Opener Supplied and Installed Airdrie
Commercial Garage Door Opener Motor
1/2 HP, 115V single phase intermittent-duty motor with instant reverse and internal automatic reset thermal overload protection. Removable without affecting limit switch settings. Also available with 50Hz motor.
Reduction
First step in reduction 5L/B V-belt drive, additional steps by chain and sprockets. Input shaft is 5/8", supported by precision ball bearings. Output shaft is 1" with 1/4" keyway, supported by ball bearings. Output shaft speed: 36 rpm.
Clutch
Friction type, positioned on input shaft, easily adjustable from outside.
Drive
#41 roller chain with a 41B12 sprocket for the operator drive shaft. Door sprocket selected for a door travel of 6"/s to 12"/s.
Brake
Mechanical Brake.
Commercial Door Manual Operation
Hoist-a-matic self-engaging hoist (floor level engagement device is not required to operate) for manual chain operation. An electrical interlock automatically disconnects power to the motor operator when chain hoist is engaged. Hoist on right is standard.
Electrical Enclosure
All electrical components are in a Nema 1 enclosure. Hinged electrical enclosure cover.
Limit System
Rotary-type oil-impregnated steel cams, commercial grade switches. Limit shaft is supported by self lubricating bronze bushings for increased precision. Remains in time when there is a manual operation or after the motor has been removed.
Accu-cam Feature
Precise and quick one-handed adjustment of the limits.
Corrosion Protection
Frame and control enclosure protected by baked on, long lasting enamel finish. Polymer control box cover. All shafts protected by yellow chromate coating.
Commercial Door Opener Mounting
Wall, hood, or shelf mounted on the right or left side of the door.
Airdrie Commercial Door Opener Control Options
24VDC relaying circuit with a 40VA class II transformer, non-volatile memory. Features available:
- 1.5s delay on reverse
- Programmable maximum run timer
- Mid-stop
- Timer to close (suspension possible from floor level)
- Independent input loop terminal
- Advanced close system
- Test buttons
- Reverse wiring detection
- Door lock sensor
Operating mode selectable on site: C2, B2, D1, E2, T or TS
Commercial Door Opener Control Accessories Airdrie
Angled terminal strip allows for the connection of 3-button stations (one supplied with the operator), non-monitored sensing edges, non-monitored photo cells, one push-button radio control (external strip), ceiling pull switches, key switches, loop detectors, external interlocks, plug-in radio card and universal auxiliary output module. 2A fuse protected 24VAC output is available for accessory power supply. NEMA 4/12 or NEMA 4X protected monitored photo cells upgrade available.
Airdrie Commercial Door Opener Mechanical Accessories
Mounting bracket for wall or wood, chain spreader, etc.
For more options contact Door Surgeon at 403-448-5625.
| Cycles | Ideal For | Clearance / Side Room Required | Max Door Height |
| 14 cycles / hour | Standard Lift | 15" | 14' |
| (50 cycles / day) | (380mm) | (4200 mm) |
Operator Range and Current Consumption (Amp)
| Horse Power | 115V - 1 HP |
| 1/2 | 5.0 |
OPERA SH
New 3/4 HP Commercial / Industrial Heavy Duty Jack Shaft Overhead Door Opener w/ Solenoid Brake Supplied and Installed in Airdrie
Standard Features
Commercial door openers that get the job done. This Opera SH 3/4 HP over head door operator is made to last.
Commercial Door Opener Motor
Has a high starting torque of 60Hz with continuous-duty, single phase capacitor start or 3 phase motor. Open drip proof, protected against overload. Also available with 50Hz 220V 1 phase and 380V 3 phase motor.
Reduction
First step in reduction 5L/B V-belt drive, additional steps by chain and sprockets. Input shaft is 3/4", supported by precision ball bearings. Output shaft is 1" with 1/4" keyway, supported by cast iron flanged pillow block bearings. Output shaft speed: 41 rpm.
Clutch
Friction type, positioned on input shaft, easily adjustable from outside.
Drive
#50 roller chain with a 50B12 sprocket for the operator drive shaft. Door sprocket selected for a door travel of 6"/s to 12"/s.
Brake
Mechanical Brake.
Commercial Door Opener Manual Operation
Has An electrical interlock that disconnects power to the motor operator when chain hoist is in operation. Hoist on right is standard.
Electrical Enclosure
All electrical components are in a Nema 1 enclosure. Hinged electrical enclosure cover.
Limit System
Rotary-type oil filled steel cams with commercial grade switches. Limit shaft that is supported by a self-lubricating bronze bushing for better precision. Remains timed when in manual operation or after the motor has been removed.
Accu-cam Feature
Precise and quick one-handed adjustment of the limits.
Commercial Door Opener Corrosion Protection
Frame & control section protected by baked-on, long-lasting enamel finish. Has a Polymer control box cover. All shafts protected by yellow chromate coating.
Commercial Door Opener Mounting
Wall, hood, or shelf mounted on the right or left side of the door.
ECB Units (BOARD 070) (OE):
24VDC relaying circuit with a 40VA class II transformer, non-volatile memory. Features available:
- 1.5s delay on reverse
- Programmable maximum run timer
- Mid-stop
- Timer to close (suspension possible from floor level)
- Independent input loop terminal
- Advanced close system
- Test buttons
- Reverse wiring detection
- Door lock sensor
Operating mode selectable on site: C2, B2, D1, E2, T or TS
Contactor Units (OO):
40VA class II transformer & 24VAC control circuit, fuse is protected on output, heavy-duty across-the-line linear reversing contractor has mechanical interlock.
Commercial Door Opener Control Accessories
Terminal is angled and allows for the connection of 3-button stations (one supplied with the operator). Has non-monitored sensing edges, non-monitored photo cells, one push-button radio control (external strip). Ceiling pull switches, key switches, loop detectors & external interlocks. Plug-in radio card and universal auxiliary output module. 2A fuse protected 24VAC output is available for accessory power supply. NEMA 4/12 for NEMA 4X protected monitored photo cells upgrade available.
Environmental Modifications
NEMA 4/12 and NEMA 4X enclosures. For NEMA 7/9 consult Door Surgeon at 403-770-5625.
Commercial Door Opener Mechanical Accessories
Wall or hood mounting bracket, chain spreader, etc. For more options contact Door Surgeon at 403-448-5625.
| Cycles | Ideal For | Clearance / Side Room Required |
| 25 cycles / hour | High Lift | 16" |
| (100 cycles / day) | Full Vertical | (406mm) |
Operator Range and Current Consumption (Amp)
| Horse Power | 115V 1 HP |
230V 1 HP |
208/230V 3 HP |
460V 3 HP |
575V 3 HP |
| 1/2 | 8.0 | 4.0 | 2.1 | 1.0 | 8.0 |
| 3/4 | 11.2 | 5.6 | 3.2 | 1.5 | 1.2 |
OTBH
New 3/4 HP Commercial / Industrial Heavy Duty Trolley Overhead Door Opener w/ Solenoid Brake Supplied and Installed in Airdrie
Standard Features
The OTBH 3/4 HP garage door opener shows its ability to deal with heavy loads and extreme climates very well.
Commercial Door Opener Motor
60Hz high starting torque, continuous-duty, single phase capacitor start or 3 phase motor, open drip proof, protected againsr overload. Also available with 50Hz 220V 1 phase and 380V 3 phase motor.
Reduction
First step in reduction 5L/B V-belt drive, additional step by #41 chain and sprockets. Input shaft is 5/8", supported by precision ball bearings. Output shaft is 1" supported by ball bearings. Output shaft speed: 120 rpm for a door travel of 12"/s.
Clutch
Friction type, positioned on input shaft, easily adjustable from outside.
Drive & Trolley Assembly
#48 (410) full roller chain drive on 1/2HP and 341 full roller chain drive on 3/4, 1HP. Dual, 12 gauge, pre-drilled galvanized tracks provided for doors up to 12' in height standard. Additional track lengths are available (max door height acceptable for the operator limit system is 30'). Track spacers 3/4" steel shaft. Trolley made of cast aluminum alloy with chain tension adjustment device.
Brake
Electrically activated drum-band type solenoid brake.
Commercial Door Opener Manual Operation
Quick release disconnect arm for manual push-up operation.
Electrical Enclosure
All electrical components are in a Nema 1 enclosure. Hinged electrical enclosure cover.
Limit System
Rotary-type oil-imregnated steel cams, commercial grade switches. Limit shaft is supported by self-lubricating bronze bushings for increased precision. Remains in time when there is a manual operation or after the motor has been removed.
Accu-cam Feature
Precise and quick one-handed adjustment of the limits.
Commercial Door Opener Corrosion Protection
Control enclosure & frame protected by baked on, long lasting enamel finish. Polymer control box cover. All shafts protected by yellow chromate coating.
Commercial Door Opener Mounting (Low Headroom Design)
Ceiling-mounted with only 6.25" headroom clearance required below the tracks.
ECB Units (BOARD 070) (OE):
24VDC relaying circuit with a 40VA class II transformer, non-volatile memory. Features available:
- 1.5s delay on reverse
- Programmable maximum run timer
- Mid-stop
- Timer to close (suspension possible from floor level)
- Independent input loop terminal
- Advanced close system
- Test buttons
- Reverse wiring detection
- Door lock sensor
Operating mode selectable on site: C2, B2, D1, E2, T or TS
Contactor Units (OO):
24VAC control circuit, 40VA class II transformer, fuse protected on output, heavy-duty across-the-line linear reversing contractor with mechanical interlock.
Commercial Door Opener Control Accessories
Terminal strip is angled and allows for the connection of 3-button stations (one supplied with the operator). Non-monitored sensing edges, non-monitored photo cells, one push-button radio control (external strip). Ceiling pull switches, key switches, loop detectors, external interlocks. Includes plug-in radio card and universal auxiliary output module. 2A fuse protected 24VAC output is available for accessory power supply. NEMA 4/12 for NEMA 4X protected monitored photo cells upgrade available.
Environmental Modifications
NEMA 4/12 and NEMA 4X enclosures. For NEMA 7/9 consult Door Surgeon at 403-770-5625.
Commercial Door Opener Mechanical Accessories
Hood or wall mounting bracket, chain spreader, etc. For more options contact Door Surgeon at 403-448-5625.
| Cycles | Ideal For | Back Room Door Height | Head Room for Tracks |
| 25 cycles / hour | Industrial Standard Lift | + 4'5" | 4" |
| (80 cycles / day) | (1350mm) | 102mm |
Operator Range and Current Consumption (Amp)
| Horse Power | 115V 1 HP |
230V 1 HP |
208/230V 3 HP |
460V 3 HP |
575V 3 HP |
| 1/2 | 8.0 | 4.0 | 2.1 | 1.0 | 8.0 |
| 3/4 | 11.2 | 5.6 | 3.2 | 1.5 | 1.2 |
New EHJ Jackshaft-Type Electric Commercial Overhead Door Operator Supplied and Installed in Airdrie
Industrial Opener Available in 1/3, 1/2, 3/4, and 1 HP
Commercial/Industrial duty
EHJ Jackshaft type electric operator has been developed primarily as an operating mechanism for commercial-industrial door equipped with head shaft. Naturally doors of either sectional overhead, vertical lift, hy-lift or rolling steel construction are ideally suited for operation by this unit. Many othertypes of doors can be equipped with this operator, providing the door has a shaft as the basic driving element.
Features:
Three Button Control:
Momentary contact type for up, down and stop. Operator may be stopped in any position and door moved up or down from that position. Operator can be wired for constant pressure down when specified. Control circuit 24V. A.C. for user's protection.
Adjustable Automatic Friction Clutch:
To protect door and operator in case of obstruction.
Reduction:
Rugged power unit of this operator utilizes a large size V belt (5L) and heavy pulleys for primary reduction, roller chain and steel sprockets for secondary reduction to the output drive shaft. Pulleys and sprockets are mounted on 1" (2.5cm) C.R. steel shaft rotating on high speed, precision, self-aligning pillow block bearings for efficient long lasting, hard working, high traffic operation. Door operating speed approx. 1.0ft. (.3m) per second.
Heavy Duty Solenoid Brake:
Made from one 4" (10cm) diameter aluminium alloy disc mounted on keyed motor shaft, brake lined shoes with 360o exterior compressing force, throw spring loaded mechanism. Brake disc stops door when electro-magnetic solenoid switch is released. Mounted on heavy duty steel plates protected in 14 ga. steel enclosure. Brake mechanism is self-adjusting type.
Limit Switches:
Screw type friction free oilite bronze cams and precision micro switches, for both up and down automatic stopping of door position, easily adjustable without tools.
Reversing Contactor:
Heavy duty type STRUTHERS-DUNN or equal.
Safety Interlock:
Electrical interlock switch automatically cuts power off on operator when chain hoist is in operation.
Commercial Door Opener Universal Mounting:
Right or left side.
Commercial Door Opener Manual Overload Relay:
For overload and under voltage protection. (Can be reset manually).
Commercial Door Opener Motor:
1/3 H.P. (.33hp), 1/2 H.P. (.5hp), or 3/4 H.P. (.75hp), or 1 H.P., 115V. or 230V., 1 phase 208V., 440V. or 550V., 3 phase. (1 H.P. not recommended in single phase motors).
Safety Electrical Interlock:
When chain hoist is in operation a normally off toggle switch cuts the power line off operator automatically. This safety electrical interlock will protect operator and door when is restored and push button station is pressed accidentally.
Commercial Door Opener Emergency Chain Hoist:
Combined with a floor operated disconnect which when pulled will disconnect the electric driven solenoid brakes and engage the chain hoist for manual operation in the event of power failure, without having to remove the main drive chain. Assembly consists of one grooved aluminium pocket wheel, lever arm, one coupling, 1/8" (.31cm) D. pull cable, 7/16" (11.1mm) D. bright polish chain, wall chain keeper and disconnect arm.
Doorlec - EHJ Jackshaft-Type Spec Drawing
Click Yellow Links Below for Detailed Information
Follow these links for related pages
Commercial Garage Door Service Airdrie
New Commercial Garage Doors Airdrie
Door Surgeon Commercial Garage Door & Overhead Garage Door Repair Fix & Replacement Service Centre Shop Calgary North East
Service Centre: Unit D, 2020 32 Ave NE, Calgary, Alberta T2E 6T4
Find us in Calgary:
Located South-side of 32 Ave, East of the Deerfoot Trail, West of Barlow Trail, South of Calgary International Airport.
Serving Airdrie and surrounding area.
Door Surgeon is a 100% Canadian local mobile commercial overhead garage door opener repair service company near you.
It's time to get Door Surgeon's commercial overhead garage door opener fix, adjust, repair or new opener installation team working for you.
WARRANTY
Sometimes Things Happen
No one likes it when things go wrong, no one more than us, but if it does check out our Warranty
New Training Centre
New Expanded 7000 Sq. Ft Training Centre
Door Surgeon™
New training & Commercial Client Care Centre located at: 17804 118 Ave NW
Door Surgeon has an extensive commercial garage door opener repair training program and now has a large facility to match the ever growing needs of developing our commercial garage door repair service team.
Long term experienced commercial garage door opener repair servicemen are involved in the training of commercial garage door opener service personnel and the updating to current standards and technology for Door Surgeon's current experienced commercial garage door opener replacement & commercial garage door opener repair service team.
Commercial garage door opener & commercial garage door replacement openers have several safety concerns that are addressed in our commercial garage door opener repair and commercial garage door opener replacement training centre.
Tools used for making commercial garage door opener repairs and commercial garage door opener replacement are reviewed and updated as needed to meet changing commercial garage door specifications.
Also, our Door Surgeon trainers focus on commercial garage door opener product knowledge, team building and ensuring our servicemen understand that the team leaders are qualified to support them in whatever commercial garage door opener repair environment they are tasked with.
Door Surgeon's commercial garage door training centre has a variety of common commercial garage door repair openers, commercial opener repair parts and tools so as to enhance the learning experience and to ensure all the Door Surgeon commercial garage door opener servicemen are capable of providing quality commercial products and professional commercial services in a safe manner.
Brand Promise
Door Surgeon™
Tested Tough Garage Doors and Hardware
Since 2008 Door Surgeon has been and continues to be committed to providing professional residential garage door and commercial garage door repair and replacement services.
A Variety of Products and services including:
- Garage door adjustment and repair service
- Spring, cable, roller, and hinge replacement
- Weatherstrip, remotes, photo-eye, track and panel repair and replacement
- Garage door opener repair and replacement
- Garage door removal and disposal
- Garage door opening preparation, adjustment and repair
- New garage door delivery and installation
- Adjustment, repair and replacement of additional parts of both residential and commercial doors as needed e.g. Shafts, bearings, drums, chain lifts, etc.
- Standard & advanced key systems
- Superior residential door hardware
- Quality commercial door hardware
- Door weatherstrip replacement
- Break & enter door repair
- Electronic access control
- Automatic door closers and openers
- Patio door and window repair
- Storm door repair and replacement hardware
- Window bars
- Safe sales
Trained professional servicemen deliver mobile repair and installation in service vehicles that are stocked with trade related tools and a large variety of commonly used repair and replacement products.
In-store sales and service counters are staffed by experienced trained door and lock servicemen that are well equipped with trade related tools and extensively stocked with products to match our customers DIY needs and customer supplied product repair needs.
Door Surgeon maintains a comprehensive policies and procedures manual outlining staff expectations. It addresses medical leave and vacation time, appropriate coffee and lunch breaks, smoking regulations—including no smoking on customers’ properties—dress codes, proper attire, safety equipment and footwear, on-site safety concerns, drug and alcohol testing, and the confidentiality and privacy of information related to payment methods, key control systems, and access control systems. It also covers many other subjects that promote professional performance, ongoing training, and courteous communication.
All our mobile door and lock service trucks are equipped with GPS tracking units that monitor and report each vehicle’s location, travelling speed, and driving activity. Our service trucks are also equipped with front- and rear-facing cameras that record vehicle incidents and help monitor driver behaviour.
Our sales and service centres carry an extensive selection of lock, door, and key parts. Our service-counter staff are either certified journeyperson locksmiths, registered apprentices in the Locksmith Apprenticeship Program or extensively trained man door and garage door repair servicemen. Every service team member—whether working in one of our shops or providing mobile service—receives hundreds of hours of company training in locks, keys, automotive ignitions, safes, and doors.
All our door, lock and key sales and service centres have security cameras that monitor and record customer and staff interactions to help ensure our service standards are consistently met. Door Surgeon’s sales and service centres are also equipped with a wide range of professional tools and the latest technology, allowing our skilled team to handle virtually any service challenge.
Thank you for considering Door Surgeon. We appreciate the opportunity to earn your business and look forward to working with you.
Door Surgeon Mobile Commercial Overhead Garage Door Opener Repair Serving Airdrie
Mobile Door Parts & Repair Services Airdrie
Trademark & Corporate Ownership Notice
The Door Surgeon™ name and logo are trademarks of
A AB. Lock Surgeon Ltd. All rights reserved.
Door Surgeon™ is a 100% Canadian service company
